Construction And Installation Hot Galvanizing Shaped Wlded Steel Tube Galvanized Steel Pipe
Shanghai T&T mainly sells galvanized steel pipe, erw steel pipe, square & rectangular pipe, galvanized custom steel sections. We can supply from stock all the year. Besides, various sizes of steel pipes can be processed and customized as required.
Quick details of galvanized steel pipes:
| Product Name | 12 Foot Galvanized Steel Pipe Schedule 80 Galvanized Steel Piping GI Round Pipe |
| Model Number | DN15---300 |
| Material | Carbon steel |
| Surface treatment process | Hot dip galvanizing |
| Application | Construction and installation Object classification Mechanical fitting connection Oil pipeline connection,etc |
| Feature | High pressure corrosion resistance |
| Custom Order | Accept |
| MOQ | one bundle for different packing |
| Samples | Available |
| Size | To meet customer size requirements |
Our Advantage:
Providing high quality products which have been exported over 100 countries, Pipes can be Customized according to customer's requirement on length and wall thickness with hot dipped galvanized or painting (surface treatment)
Specifications of galvanized steel pipe:
| Diameter | OD | Thickness | Big Thickness |
| mm | in | Size mm | Thickness mm | Weight kg/m | Thickness mm | Weight kg/m |
| 6 | 1/8 | 10 | 2 | 0.39 | 2.5 | 0.46 |
| 8 | 1/4 | 13.5 | 2.25 | 0.62 | 2.75 | 0.73 |
| 10 | 3/8 | 17 | 2.25 | 0.82 | 2.75 | 0.97 |
| 15 | 1/2 | 21.2 | 2.75 | 1.26 | 3.25 | 1.45 |
| 20 | 3/4 | 26.8 | 2.75 | 1.63 | 3.5 | 2.01 |
| 25 | 1 | 33.5 | 3.25 | 2.42 | 4 | 2.91 |
| 32 | 1+1/4 | 42.3 | 3.25 | 3.13 | 4 | 3.78 |
| 40 | 1+1/2 | 48 | 3.5 | 3.84 | 4.25 | 4.58 |
| 50 | 2 | 60 | 3.5 | 4.88 | 4.5 | 6.16 |
| 65 | 2+1/2 | 75.5 | 3.75 | 6.64 | 4.5 | 7.88 |
| 80 | 3 | 88.5 | 4 | 8.34 | 4.75 | 9.81 |
| 100 | 4 | 114 | 4 | 10.85 | 5 | 13.44 |
| 125 | 5 | 140 | 4.5 | 15.04 | 5.5 | 18.24 |
| 150 | 6 | 165 | 4.5 | 17.81 | 5.5 | 21.63 |
Material Analysis:
| Elements | Chemical Composition% | Mechanical Property |
| Material | C% | Mn% | S% | P% | Si% | Yield Point | Tensile Strength | Elongation |
| | | | | | | (Mpa) | (Mpa) | (%) |
| Q195 | 0.06-0.12 | 0.25-0.50 | <0.05 | <0.045 | <0.3 | >195 | 315-430 | 32-33 |
| Q235 | 0.12-0.2 | 0.30-0.70 | <0.045 | <0.045 | <0.3 | >235 | 375-500 | 24-26 |
| Q345 | <0.20 | 1.0-1.6 | <0.04 | <0.04 | <0.55 | >345 | 470-630 | 21-22 |
Deep Processing Service
1. Pipe Cutting: cut into new length.
2. Bending
3. Screw Thread
4. Painting
We can deep processing according to the drawings.
Packing:
1.In bundle, black, caps, beveled ends or plain ends
2.OEM/ customer's REQUEST
3.Marks: Standard * Material*OD*WT*L *Lott No./required
Shipping:
a. Length: ≤5.85m, loaded in 20FT Container, Max 22tons
b. Length: ≤11.85m, loaded in 40 FT Container, Max 27tons
c. Length: ≥12m, shipped by bulk vessel. FILO terms
Delivery time :about 20-30 days after received deposit.
Our advantage
1. Our products’ raw material is high quality hot dipped zinc galvanized steel strip, absolute fireproof and heat insulation, waterproof and antirust, anticorrosive , high durability
2. Hot dipped zinc galvanized steel strip zinc coating is 80-180g/m2.
3. Double sized galvanization volume make sure that the plaster bone is corrupt and rust resistance.
4. Warm sales in Middle East, Africa , Australia, Malaysia ,and America , which have enjoyed an excellent reputation with high quality and services.
5. manufacture the special specification products for customers
6. High quality raw material guarantees the light steel keel of life and good performance of construction.
7. Posessess own ten precision cold rolled steel strip production line.
FAQ
Q1: Can I have a sample?Is it free?
A: Yes,sample is offered for free, but freight shall be charged by customer.
Q2: What about the lead time?
A: Normally 7-10 working days for normal specification,2-5days if we have in stock.
Q3: Do you have MOQ limit?A:It depends on products, normally we can do as client requires.
Q4: What about your payment term?
A:T/T or L/C,Western Union, it can be negotiated.
Q5: What is your warranty?A:Mill test certificate,SGS certificate, MTC certificate, shipping inspection or any thirs
party as you need.
